Teadit® 913M-10-300#-304-GRAPHITE

Teadit® Metalflex® 913M-10 304 Stainless Steel Spiral Wound Gasket with Inner Ring, 10 in, 300 lb, Gray/Yellow

  • Manufacturers: Teadit
  • Brand Name: Teadit®
  • Tipco Part No: TEA 913M-10-300#-304/304-GRAPHITE
  • MPN: 913M-10-300#-304-GRAPHITE
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Teadit® Metalflex® Spiral Wound Gasket with Inner Ring, Nominal Size: 10 in, 11.31 in ID, 12-1/2 in OD, 300 lb, 842 deg F, 304 Stainless Steel, Gray/Yellow, For Use With: ASME B16.5 and ASME 16.47 A/B Flanges, Inner Ring: Yes, Filler Material: Graphite, Operating Pressure: 300 psi

Product Type      :      Spiral Wound Gasket
Pressure Rating      :      300 lb
Temperature Rating      :      842 deg F
Material      :      304 Stainless Steel
Color      :      Gray/Yellow
For Use With      :      ASME B16.5 and ASME 16.47 A/B Flanges
Inner Ring      :      Yes
Filler Material      :      Graphite
Operating Pressure      :      300 psi
Nominal Size      :      10 in
Inside Diameter      :      11.31 in
Outside Diameter      :      12-1/2 in

The 913M is the standard spiral wound gasket with an inner ring. The purpose of this ring is to fill out the space between the flanges, avoiding turbulence in the flow of the fluid or as protection against corrosion or erosion. It is also used as a compression limit. Inner rings are also required with ASME standard spiral wound gaskets with flexible graphite fillers.

Standards/Certifications: ASME B16.20

Applications: For use in ASME B16.5 and ASME 16.47 A/B flanges
